Product Description
According to the definition in GB/T20878-2007, stainless steel is mainly characterized by stainless steel and corrosion resistance, and the chromium content is at least 10.5%, and the carbon content is not more than 1.2%.
Stainless steel is the abbreviation of stainless and acid-resistant steel. The steel that is resistant to weak corrosive media such as air, steam, and water or has stainless steel is called stainless steel. The steel grade is called acid-resistant steel.
Due to the difference in chemical composition of the two, their corrosion resistance is different. Ordinary stainless steel is generally not resistant to chemical medium corrosion, while acid-resistant steel is generally stainless. The term "stainless steel" does not simply refer to one type of stainless steel, but to more than one hundred industrial stainless steels, each developed to perform well in its specific field of application. The key to success is to first understand the application and then determine the correct steel grade. There are usually only six steel grades associated with building construction applications. They all contain 17-22% chromium, and the better grades also contain nickel. The addition of molybdenum can further improve atmospheric corrosion, especially corrosion resistance to chloride-containing atmospheres.
Generally speaking, the hardness of stainless steel is higher than that of aluminum alloy, and the cost of stainless steel is higher than that of aluminum alloy.
| Product Name | AISI ASTM Stainless Steel Plate 201/304/316/321/904L/2205/2507 |
| Type | Cold rolled or Hot Rolled |
| Thickness | 0.1-150mm |
| Width | 1000, 1219, 1500, 2000, 2500, 3000mm etc. |
| Length | 1000, 1500, 2438, 3000, 5800, 6000, 9000, 12000mm etc. |
| Standard | ASTM JIS AISI GB DIN EN |
| Surface Finished | BA, 2B, NO.1, NO.4, 4K, HL, 8K |
| Application | construction field, ships building industry, petroleum,chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and hardware fields |
| Certification | CE, ISO, SGS, BV |
| Technique | Hot rolled or cold drawing |
| Edge | Mill Edge / Slit Edge |
| Quality | SGS Inspection |
| Grade(ASTMUNS) | 201 202 301 304 304L 321 316 316L 317L 347H 309S 310S 904L S32205 2507254SMOS 32760 253MA N08926 etc. |
| Grade (EN) | 1.4301. 1.4307, 1.4541, 1.4401. 1.4404 .1.4571. 1.4438, 1.4539. 1.4547.11.4529, 1.4562, 1.4410, 1.4878, 1.4845, 1.4828, 1.4876,2.4858, 2.4819 |
| NO | T*W*L (MM) | NO | T*W*L (MM) | NO | T*W*L (MM) |
| 1 | 0.3*1000*2000 | 20 | 1.5*1219*2438 | 39 | 24.0*1500*6000 |
| 2 | 0.3*1219*2438 | 21 | 2.0*1000*2000 | 40 | 25.0*1500*6000 |
| 3 | 0.4*1000*2000 | 22 | 2.0*1219*2438 | 41 | 30.0*1500*6000 |
| 4 | 0.4*1219*2438 | 23 | 2.5*1000*2000 | 42 | 35.0*1500*6000 |
| 5 | 0.5*1000*2000 | 24 | 2.5*1219*2438 | 43 | 40.0*1500*6000 |
| 6 | 0.5*1219*2438 | 25 | 3.0*1000*2000 | 44 | 45.0*1500*6000 |
| 7 | 0.6*1000*2000 | 26 | 3.0*1219*2438 | 45 | 50.0*1500*6000 |
| 8 | 0.6*1219*2438 | 27 | 3.0*1500*6000 | 46 | 55.0*1500*6000 |
| 9 | 0.7*1000*2000 | 28 | 4.0*1500*6000 | 47 | 60.0*1500*6000 |
| 10 | 0.7*1219*2438 | 29 | 5.0*1500*6000 | 48 | 65.0*1500*6000 |
| 11 | 0.8*1000*2000 | 30 | 6.0*1500*6000 | 49 | 70.0*1500*6000 |
| 12 | 0.8*1219*2438 | 31 | 8.0*1500*6000 | 50 | 75.0*1500*6000 |
| 13 | 0.9*1000*2000 | 32 | 10.0*1500*6000 | 51 | 80.0*1500*6000 |
| 14 | 0.9*1219*2438 | 33 | 12.0*1500*6000 | 52 | 85.0*1500*6000 |
| 15 | 1.0*1000*2000 | 34 | 14.0*1500*6000 | 53 | 90.0*1500*6000 |
| 16 | 1.0*1219*2438 | 35 | 16.0*1500*6000 | 54 | 95.0*1500*6000 |
| 17 | 1.2*1000*2000 | 36 | 18.0*1500*6000 | 55 | 100.0*1500*6000 |
| 18 | 1.2*1219*2438 | 37 | 20.0*1500*6000 | 56 | 105.0*1500*6000 |
| 19 | 1.5*1000*2000 | 38 | 22.0*1500*6000 | 57 | 110.0*1500*6000 |
